Ball Nut

Ball Nut, 1.500 in X 0.250 in, Round, With Safety Feature, Non-Preloaded, 捡拾齿, 4050 lbf

仅螺母
经过质量检测，确保可靠的性能
具有可靠的精度和可重复性，且价格实惠

尺寸

Dimension	Value
Unit Of Measure	All length values in: inches

dimensions

Dimension	Value
Unit Of Measure	All length values in: inches

规格

Specification	Value
Diameter	1.500 in
导程	0.250 in
Nut Material	Alloy Steel
Nut Style	Precision
Screw Part Number	190-9133
Number Of Starts	1
Total Weight	1.50 lbs

性能

Performance	Value
Load, Dynamic	18,015 N (4,050 lbf)
Load, Static	211,068 N (47,450 lbf)
